NewClassic 275 v.2 stereo stiprintuvas
Parasound
1690 €
- 90 watts x 2 into 8 Ω (all channels driven)
- 150 watts x 2 into 4 Ω or 2 Ω (all channels driven)
- 200 watts x 1 bridged into 8 Ω or 4 Ω
- 20 amps peak current per channel
- 2 Ohm stable operation with load selector switch
- Two pairs of speaker outputs with front panel A/B buttons
- Rear-mounted lockout switch disables front A/B buttons
- High pass filter, switchable for 20Hz or 40Hz
- Automatic on/off by DC trigger with looping output
- Automatic on/off by audio signal with 2 sensitivity settings
- Fully discrete circuitry with high current toroid transformer
- Bridging switch for stereo or mono operation
- Efficient, low heat design
- DC Servo and relay protection circuits
- Rear-mounted left and right gain controls
- Standby, channel status and high temperature indicators
- Gold-plated RCA input jacks
- Heavy duty 24k gold-plated 5-way speaker terminals
- 115/230v selector on rear panel
- 1U rack mount kit available separately (Model RMK11)
Techninė specifikacija:
Power Output - (RMS power, 20 Hz - 20 kHz) All Channels Driven
90 watts x 2, 8Ω; 150 watts x 2, 4Ω; 150 watts x 2, 2Ω (Load switch set to 2-3Ω)
Bridged Mono
200 watts x 1, 8Ω; 200 watts x 1, 4Ω (Load switch set to 2-3Ω)
Current Capacity
20 amps peak per channel
Frequency Response
20 Hz - 50 kHz, +0/-3 dB, 1 watt
Dynamic Headroom
1.3 dB
Total Harmonic Distortion
0.35% at full rated output; 0.025% at average listening levels
IM Distortion
0.05 %
S/N Ratio
110 dB at rated output, IHF A-weighted; 103 dB at rated output, unweighted; 93 dB at 2.828 V output, IHF A-weighted; 84 dB at 2.828 V output, unweighted
Input Impedance
33 k Ω
Input Sensitivity
800 mV for full rated output (28dB)
Inter-Channel Crosstalk
80 dB @1 kHz, 72 dB @10 kHz, 65 dB @ 20kHz
Damping Factor
Over 150 at 20Hz
12V Trigger Turn On
DC 9 - 12V, 15 mA
Audio Turn On
Quieter: 1 mV; Louder: 6 mV
AC Power Requirement
110 - 120 V / 220 -240 V, 50 - 60 Hz; 0.5 watts standby; 25 watts Idle (no audio); 350 watts full output
Dimensions
17-1/4" Wide; 16" Deep, with cables connected; 2-1/2" High with feet, 1-3/4" panel only (1U); (437 x 406 x 63mm, 44.1 mm panel only)
Net Weight
20 lbs (9.1 kg)
Rack Mount Accessory
May be Purchased Separately; RMK11
