Architect 110 stereo stiprintuvas

Audiocontrol
899 €

Features:

  • 240 watts per channel RMS output into 2 ohms
  • Bridged power of 410 watts
  • Ultra low current consumption of <1 watt at standby!
  • Dual speaker output terminals for each channel (optional 5-way binding posts)
  • Main plus Auxiliary inputs with Signal-Sense Turn-On
  • Stereo/Mono control
  • Cool blue front panel Status LED indicators
  • Signal present LED’s on speaker outputs
  • PFM Subsonic filter for speaker protection
  • AudioControl LightDrive protection circuit
  • Signal sensing inputs
  • Rack mountable front panel (Non-Rack option available)

2 channel high-current amplifier


Do you want superb sound quality while driving eight speakers from a two-channel distributed audio amplifier? Do you want AudioControl legendary reliability and performance with amazing energy efficiency? Then the waiting is over as AudioControl introduces its new high powered, great sounding stereo power amplifier, the Architect Model 110. All of these are standard features of the new AudioControl Architect Model 110 amplifier as it will comfortably drive 8 speakers (stable into 2 ohms) and has an astonishingly low energy usage, meeting the new stringent Energy Star requirements.


The AudioControl Architect Model 110, is a unique two-channel amplifier specially optimized for multi-room needs. The Architect Model 110 also boasts the meticulous quality and bulletproof reliability for which AudioControl’s custom-install designs are widely known.

INPUTS

Inputs
1 Stereo Main, 1 Stereo Aux

Input Maximum
8V

Input Impedance
15kΩ

OUTPUTS

Amplifier Channels
2 (4 terminal blocks), optional 5-way binding posts

Power Output (8Ω)
60W per channel

Power Output (4Ω)
120W per channel

Power Output (2Ω)
240W per channel

Power Output (Bridged Mono)
410W

Minimum Speaker Load

PERFORMANCE

Damping Factor
>200

Total Harmonic Distortion
<0.9%

Signal to Noise
>105dB, A-wtd ref Full Output

Crosstalk
>80dB @ 1kHz

CONTROL

Remote Power Trigger: +12 VDC

GENERAL

Power Consumption (Standby)
<1W

Power Consumption (Idle)
8W

Power Consumption (loud listening level)
30W

Power Consumption (maximum)
550W

BTU/Hour Heat Dissipation (Idle)
25

BTU/Hour Heat Dissipation (loud listening level)
200

BTU/Hour Heat Dissipation (maximum)
490

Protection
clipping, short circuit, thermal, ultrasonic, DC offset, stable into reactive or mismatched loads

WEIGHTS & DIMENSIONS

Dimensions
17”W x 12”D x 3.5”H (2U)

Weight
19.0lbs (8.62kg)
