CAD-300SEI integruotas stiprintuvas
Tube aficionados have long known that the best possible realism and detail comes when an amplifier is run in SET mode, or Single-Ended Triode. This lets one power tube handle both sides of each musical waveform, eliminating some of the most fatiguing distortions. It results in lower output power, naturally, but with high-efficiency speakers played at reasonable levels, its ultimate simplicity means the ultimate in musical naturalness.
While only offering 15 watts per channel of pure class-A remote-controlled power, the CAD-300SEI does things that almost no other amplifier today can achieve. Its careful attention to design and construction means that it is extremely quiet, allowing the tiniest musical details to float against a background of dead silence. This will help you perceive more accurate soundstaging and imaging cues, as well as the most realistic harmonic structure of each instrument. You can tell a Steinway from a Bösendorfer piano, a Stradivarius from a Guarneri or Amati violin, or a Fender from a Gibson guitar. You’ll hear inner details of musical groups that you never knew were there. Sometimes the simplest IS the best, and the CAD-300SEI is a testament to that philosophy.
Techninė specifikacija
Single-Ended Class A
15 watts
.42 Volt for full output
-90 dB below full output
20 Hz to 23 KHz +/- .75 dB
CD, AUX1, AUX2, Headphone jack
1 ea – 6SN7 Input 2 ea – 6SN7 Driver 2 ea – 300B Output
1 ea – EI Laminate, 200% Duty Cycle
2 ea – EI Laminate Air Gap, 200% Duty Cycle
1% Metal Film
Polypropylene Film with hand soldered copper terminals (optional upgrades available)
2 ea – 1200µF@250 VDC
3 Conductor, Detachable
117/234 VAC @ 50/60 Hz
107 watts – Operation
3 Minutes
100 hours of playing time
Anthracite black chassis with silver or black aluminum faceplate
51 lbs
8″ H x 14″ W x 14″ D
