FT-763SM（R）
6.3mm stereo Connector
RATING
Premier Performance and Legendary Build Qualitly
Furutech’s beautifully finished, beautiful sounding FT-763SM connectors are the result of meticulous engineering and careful audition of various suitable materials. The FT-763SM features a one piece construction α (Alpha) pure copper conductor with special grade nylon glass fiber resin insulation for minimal impedance and stainless housing for superior damping.
FEATURES
Main conductor: One-piece Rhodium-plated α (Alpha) Pure copper conductor
Ground conductor: Rhodium-plated α (Alpha) Hybrid Copper conductor
Insulation: special grade Nylon Glass Fiber Resin
Housing: Stainless
Cable Clamp: Copper Alloy
Specified for core insulation diameters up to 8.0mm
Connections: Soldered
Dimensions: Housing: 12.24ψx 37.25mm overall length; Total overall length: 70.5 mm approx.
SPECIFICATIONS
•Specified for wire outer diameters up to 8.0mm
•Dimensions: Housing: 12.24ψx 37.25mm overall length
Total overall length: 70.5 mm approx.
