Heimdall+ Cinemascope projektorius
High brightness & wide color meets compact & quiet.
Heimdall is the Norse god who illuminates the world. Our Heimdall guards the Bifrost, having a wide color gamut, capable of displaying vibrant and true-to-life colors, much like the full spectrum of a rainbow.
Heimdall Cinemascope is everything you ever wanted in a home cinema projector… A stunning picture with REC2020 color gamut in Cinemascope format. RGB laser with 4,500 lumens makes large screens shine. HDMI™ 2.1 provides the latest connectivity. Multiple lens options provide installation flexibility. And, Barco Residential can’t wait to show you additional functionality coming with future firmware updates!
- 6K Cinemascope (6,144 x 2,592)
- 6,000 ANSI Lumens
- Solid state RGB Laser
- REC.2020 color gamut
Specifications
- Projector type
- 4K 1-chip DLP RGB laser projector
- Light source lifetime
- 25,000 hours: 100% power/25°C/sea-level
- Installation
- Free Rotation
- Technology
- Single Chip 4K DMD, Solid State RGB Laser
- Resolution
- Up to 6,144 x 2,592 pixels
- Aspect ratio
- 2.37:1
- Light source
- Solid State RGB Laser
- Light output
- 6,000 ANSI lumens
- Contrast ratio
- Up to 20,000:1 (with DynaBlack)
- Input resolutions
- Including and up to: 6,144 x 2,592 @ 60Hz
- Lens range
- Note: All throw ratios adjusted for 0.98” DLP device0.53:1 (EN67)*
0.70-1.06:1 (EN66)*
0.83-1.14:1 (EN76)*
1.06-1.50:1 (EN63)*
1.10-1.61:1 (EN83)
1.48-2.18:1 (EN61)*
2.19-4.05:1 (EN64)*
* Requires York lens adaptor (R9802623) for FLDX/FLD+ lenses
- Optical lens shift
- Varies depending on lens
- Color correction
- P7 RealColor™
- Color gamut
- REC709, DCI-P3, 98% REC2020
- Image processing
- Embedded warp & blend engine
- Network connection
- 10/100/1000 Mbit
- Operational humidity
- 20 – 80% RH
- HDR
- HDR10, HLG
- Inputs
- HDMI 2.1 (HDCP 2.3)
- Control
- IR, RJ45, Optional Cabled Remote
- Storage temperature
- -20 to 60 °C
- Shipping dimensions (WxLxH)
- 560 x 765 x 410 mm / 22.1 x 30.1 x 16.1 in. (excluding lens)
- Storage humidity
- 10 – 90% RH
- Power requirements
- 7-3A, 100-240V~, 50/60Hz
- Certifications
- CE, FCC Class A and cCSAus
- Power consumption
- 610W typical, 750W maximum
- Noise level (typical at 25°C/77°F)
- 30dB (29dB at 20°C/68°F)
- Operating temperature
- 10 – 40°C (sea level)
- Operating humidity
- 20 – 80% RH
- BTU per hour
- 2,081 BTU/h typical, 2,545 BTU/h maximum
- Dimensions (WxLxH)
- 473 x 563 x 293 mm / 18.6 x 22.2 x 11.6 in (excluding lens and feet)
- Weight
- 31 kg/68 lbs
- Warranty
- Limited 3 years parts and labor, extendable up to 5 years
- Safety requirements
- RG2*
*Only lenses specified in the installation manual are permitted for installation.
*This projector may become RG3 when no lens is installed.
