Stellar Gain Cell DAC keitiklis

PS Audio
2290
What happens when you take a highly respected, cutting edge DAC, like our own NuWave DSD, and connect it to your power amplifier through an analog preamp? Audio nirvana. It turns out that a great analog preamp preserves a DAC’s magic. Together, DAC and preamp form a new class of product whose sum is greater than its parts. Stellar Gain Cell DAC. A redefined and improved NuWave DSD and a Gain Cell analog preamplifier in one chassis. Think of the Stellar Gain Cell DAC as a complete analog control center with an exceptional performing DAC at its heart. All the features and functions you’d ever want in a DAC are right here in Stellar. Pure DSD, asynchronous USB, Digital Lens technology, I²S to connect to our best transport, balanced throughout, analog volume control. Replace your preamplifier, your DAC—or both—and be stunned at the level of improvement when the full and rich tapestry of music surprises and delights your senses. In the more than forty years of PS Audio’s design innovations and breakthrough products, Stellar’s groundbreaking level of performance as our gateway standalone DAC and preamplifier is unmatched for price and performance by their standalone competitors. Taken together, we’re willing to bet you’ve never heard anything quite this good at anywhere even remotely close to this price.
Stellar Gain Cell DAC keitiklis

Techninė specifikacija:

Analog Inputs
RCA: 3 stereo pair; XLR: 1 stereo pair

Digital Inputs
I2S: 1 PCM (384KHz max) DSD64 DSD128; Coax: 2 PCM (192KHz max); Optical: 1 PCM (96KHz max); USB: PCM (384KHz max), DSD64 (DoP) DSD128 (DoP)

Format
PCM, DSD

Analog Audio Outputs
RCA: 1 stereo pair; XLR: 1 stereo pair; Headphones: One 1/4" headphone connector front panel

Gain
12dB +/-0.5dB

Maximum output
20 Vrms

Sensitivity
5.3Vrms

Input Impedance
47KΩ single ended RCA; 100KΩ Balanced XLR

Output Impedance
100Ω single ended RCA; 200Ω balanced XLR

Frequency Response
20Hz – 20KHz +0/- 0.25dB; 10Hz – 100KHz +0.1/-3.0dB

Noise
20-20KHz <-90dBV

S/N Ratio
1KHz >110dB (max output)

Channel separation
1KHz >90dB

Input separation
1KHz >90dB

THD&IM
1KHz < 0.025%, 20-20KHz < 0.05%

Power Consumption
20W

Unit Weight
6.1 kg
