ASP880 8 kanalų pradinis stiprintuvas

Name: ASP880 8 kanalų pradinis stiprintuvas
SKU: 3125
Price: 999 EUR
Availability: InStock

Audient

999 €

Aprašymas

Techninė specifikacija

8 Channel Mic Pre with Variable Impedance and HPF

Audient Console Mic Pres

We are the only company that use the same Class-A mic pre design throughout our entire product range, whether you’re in the studio with an Audient console or on the road with ASP880, you’re always guaranteed the same world class Audient sound.

Pristine Converter Technology

ASP880 provides you with the highest grade converters from Burr Brown, the leaders in converter technology. The integral ADC guarantees you will have the best conversion possible. This isn’t just the best converter in a mic pre either, it stands up against dedicated converters too. Focus on the music and let ASP880 take care of the rest.

MICROPHONE PREAMPLIFIERS

MIC GAIN

-10 to +60dB (-10dB Pad)

LINE GAIN

-16 to +44dB (-10dB Pad)

PHANTOM POWER

48v +/-4v @ 10mA/Channel

MIC EIN

<-127.5dBu

CMRR

>80dB @ 100 to 10kHz

MAXIMUM INPUT LEVEL

+22dBu (+32dBu with Pad)

INPUT IMPEDANCE

Mic LO: 220Ω Balanced; Mic MED: 1k2Ω Balanced; Mic HI: 2k8Ω Balanced; Line (All Z): >6kΩ Balanced

FREQUENCY RESPONSE

+/-0.5dB 10Hz to 100kHz

CROSSTALK

<-85dBu @ 1kHz & 10kHz

THD+N @ 0dBu (1kHz)

0.003% (-90.5dBu)

SNR

>90dB

HPF

Sweepable from 25Hz to 250 Hz, 2nd Order (12dB/Octave)

DISCRETE JFET D.I (Channels 1 & 2)

D.I GAIN

-10 to +60 dB (-10dB Pad)

MAXIMUM INPUT LEVEL

+16dBu (typical), +22dBu

INPUT IMPEDANCE

1MegΩ Unbalanced

FREQUENCY RESPONSE

+/-0.5dB 10Hz to 50kHz

THD+N @ 0dBu (1kHz)

<0.03% (-70dBu)

SNR

89dB

LINE OUTPUTS (Insert Sends)

MAXIMUM OUTPUT LEVEL

+27.5dBu

OUTPUT IMPEDANCE

<100Ω Balanced

ADC LINE INPUTS (Insert Returns)

MAXIMUM INPUT LEVEL

+18dBu

DIGITAL REFERENCE LEVEL

0dBFS = +18dBu

INPUT IMPEDANCE

>10kΩ Balanced

FREQUENCY RESPONSE

+/-0.5dB 10Hz to Fs/2

CROSSTALK

<-80dBu @ 1kHz & 10kHz

THD+N @ -1dBFS (1kHz)

<0.002% (-94dB)

THD+N @ -6dBFS (1kHz)

<0.002% (-94dB)

DYNAMIC RANGE

113dB un-weighted; 115dB A-weighted

PEAK LED LINEUP

+16dBu (-2dBFS)

SIGNAL LED LINEUP

Variable Brightness from -30dBu to -10dBu (-28dBFS)

DIGITAL i/o

ADAT 8 CHANNELS SMUX

44.1 - 96kHz

AES | S/PDIF 8 CHANNELS

44.1 - 96kHz

CLOCK

Internal or External

WORLDCLOCK INPUT

75Ω BNC; Optional 75Ω Termination
