Horus keitiklis
The World’s Best Analog Section and Converters... Full Stop.
After hundreds of comparison tests made by some of the world’s most “golden eared” engineers, we can say this with a strong sense of confidence.
The Networked Audio range of converters brings Swiss-precision and un-ending attention to detail in every single component and signal path and results in the most astonishing of record and reproduction signal paths of any audio interface or converter available today.
- Hand matched and hand soldered analog componentry.
- AKM AK5578 A/D chip with modified HPF for enhanced performance (AKD8D/DP)
- Ardatech AT1201 A/D chip with modified HPF for enhanced performance (AD8D/DP)
- Individually calibrated quartz clocking mechanism
- Each channel must pass over 30 noise, distortion, CMRR and level threshold tests
- Completely balanced signal path direct to the AD
- A/D and D/A samplerate support from 44.1 -> 384kHz, DXD & DSD64/128/256
IOC-HORUS Specifications
Case Material
Powder Coated Steel
Front Panel Material
Brushed Aluminum
Weight
6.5 kg
Dimensions (2U rack mounting)
483 x 320 x 89 mm
Power Consumption (Max)
< 120 Watts
Front Panel TFT size/resolution
4.3” / 480 x 272 pixels
Headphone Monitor Jacks
Max Output Level (Unbalanced) Load = 300 Ohms
+15 dBu
Output Impedance
75 Ω
Dynamic Range (A-weighted, typ)
109 dB
THD+N (1 kHz) @ -2 dBFS
< -100 dB (0.001 %)
Gain Range (software controlled)
-60 dB to +12 dB
Gain Step/Precision
1dB / ±0.05 dB
Connectors
Sync Cable (LTC/Video Ref) DB15
D-Sub 15Pin
LTC In & Out (via “Sync” Cable)
Balanced XLR
Video Reference In (via “Sync” Cable)
BNC
Word Clock Input (Switchable 75 Ω Termination)
BNC, 0.5Vp-p min
Word Clock Output (Zout = 35 Ω)
BNC, 5Vp-p
AES type/pinout
DB-25/AES59 (Tascam)
MADI types (Coaxial / Optical)
BNC / SC
Headphone Jack 1&2
6.3 mm(1/4”)/3.5mm
RAVENNA (GbE)
RJ45
