G512-Pro pasyvi kolonėlė

Coda Audio
2290 €
CODA’s G-Series boxes are made with versatility in mind: full range systems that incorporate top end drivers; as a result, they’re suitable for a wide range of applications. The G500 Series includes the G512-Pro, G515-Pro, and the G-15 and G-18 subs. As is always the case with CODA, it all starts with the drivers: it’s a compact, smart 2-way system with wide dispersion, incorporating top quality patented annular 1-inch HF drivers, and ultra-low distortion neodymium woofers with a 3-inch voice coil and triple demodulation rings. The G512-Pro boasts a power handling of 600W and has a 12-inch neodymium cone driver, with a 1-inch compression driver on a 90° x 60° rotatable elliptical waveguide. These are no ordinary compression drivers, of course: the HF drivers contain CODA’s unique CuCup technology, which dramatically reduces intermodulation distortion, and in turn, deliver the most pristine and transparent audio. It’s also simple to mount these boxes on walls or ceilings thanks to its M6 flying points for optional U-brackets, making them a no-brainer for any touring or install application: they’re a great choice for bands, stage monitoring, DJs, clubs, and installations. Low end reinforcement comes courtesy of the compact G-15 and G-18 subs, with 15-inch and 18-inch neodymium ultra-low distortion woofers respectively. Both are high output, packing a serious punch at 1200W – the perfect partner to the two tops.
G512-Pro pasyvi kolonėlė

Techninė specifikacija:

Type

2-way full range system, multidesign enclosure


Application

High quality short throw or stage monitor


Frequency response

60 Hz – 21 kHz (-3 dB)


Power handling AES

600 W


Peak power

2400 W


Sensitivity

98 dB


Max. SPL peak (with LINUS10)

132 dB


Dispersion

90° horizontal / 60° vertical


Low frequency

12″ neodymium woofer, 3″ (77 mm) voice coil, 600W (AES)


High frequency

1″ neodymium compression driver, 1.75″ (44.4 mm) voice coil, 80 W (AES)


Crossover

1300 Hz passsive


Nominal impedance

8 Ω (+1/-1)


Input connectors

2x Neutrik™ NL4MP


Suspension

M6 threated points for use with optional U-bracket


Suspension G512-Pro

M8 threated points for use with optional U-bracket


Enclosure material

15/18 mm birch plywood


Finish

Polyurea coating


Dimensions (WxHxD)

348 x 630 x 320 mm


Net weight

16 kg


G512-Pro pasyvi kolonėlė

G512-Pro pasyvi kolonėlė

Coda Audio
2290 €
